Roof Hatch - 30" x 96" - Aluminum - Mill / Silver Color - Personnel Series - Babcock Davis - BA3096

Roof Hatch - 30" x 96" - Aluminum - Mill / Silver Color - Personnel Series - Babcock Davis - BA3096

Roof Hatch - 30" x 96" - Aluminum - Mill / Silver Color - Personnel Series - Babcock Davis - BA3096

$3,778.60


FREE SHIPPING
SKU BA3096

The Personnel Roof Hatch delivers enhanced weather resistance in a convenient, ready-to-ship format. Designed for performance and flexibility, it supports OSHA-compliant safety railings and is available in multiple sizes, materials, and finishes.

Key Features

  • Miami-Dade & Florida approval (up to 20 ft²)

  • Safety railing compatible

  • Durable powder-coated finish

  • Smooth gas spring-assisted opening


Roof Hatch Access: Service Stair

Color: Mill finish (silver, standard metal color)

  • Free Shipping
  • Need a written quote? Request Online
  • Questions?  Call (800) 604-5537

Specifications

Model BRHU
Material Aluminum
Finish Mill Finish (silver, standard metal color)
Cover Formed metal cover with liner internally stiffened to withstand a live load of 40 psf with a max deflection of 1/150 the span
Curb Single wall curb with railing‑ready EZ tab counterflash and mounting flange
Insulation 1 inch polystyrene in cover, 1 inch polyiso around curb; R‑6
Gasket Extruded EPDM adhesive‑backed gasket seal, continuous around curb and cover to assure a continuous seal
Hold Open Arm Zinc plated steel automatic hold open arm locks cover in open position
Latch Zinc plated steel latch with exterior and interior turn handle and padlock hasp; tested to 140 psf wind uplift
Warranty Five (5) years
Certification Florida Product Approval, Miami‑Dade County Approved NOA# 21‑1201.01, Expiration Date May 25, 2027
Spring Gas spring with damper for smooth, controlled lift assistance
Hinge Heavy‑duty pintle hinge with stainless steel hinge pin
Pull Handle Interior safety pull‑down handle, yellow powder coat

Documents

To download product documents such as specs, shop drawings, warranty and installation information visit the Personnel Series Roof Hatch Document Download Page >

Product Videos

Roof Hatch Gas Spring Installation

Hold Open Arm

Turn Handle

2-Point Latch & Turn Handle

Catch

2-Point Catch

Installing Rivnuts

Spring Pack

Hold Open Arm Change, Right to Left

Flash Built-Up Roof, Hot Application

Shipping Time

  • All Roof Hatches ship for free (standard ground, see map)
  • Call: (800) 604-5537 for pricing and shipping questions.

Shipping estimates shown on the map pertain to this specific product only. Roof Hatch orders ship within 5 business days. Transit times displayed in the map are listed in business days, and are approximate. Transit times are subject to stock levels at regional warehouses.  The day that the order is shipped is not counted as a transit day.
